Int J Pharm Pharm Sci, Vol 11, Issue 4, 12-15Original Article


SIMPLE METHOD FOR OPTIMIZATION OF HEPARIN AND ENOXAPARIN DETECTION USING AGAROSE GEL ELECTROPHORESIS

AHMAD A. ALMEMAN

Pharmacology Department, College of Medicine, Qassim, Qassim University, PoBox 54, Code 51911
Email: ahmadalmeman@gmail.com

Received: 26 Dec 2018 Revised and Accepted: 15 Feb 2019

ABSTRACT

Objective: A simple gel electrophoresis method for low-molecular-weight heparins (LMWH) is required for use in a variety of laboratories to allow further identification and purification. This study aimed to optimize the detection of heparin and enoxaparin (low-molecular-weight heparin by gel electrophoresis.

Methods: Several gel electrophoresis conditions were tested to optimize the detection of enoxaparin by using a simple method with a modified Volpi’s approach. Multiple gel thicknesses, voltage settings, and enoxaparin concentrations were tested in the optimization procedure. Enoxaparin was purchased from a local supplier as pre-filled pharmaceutical injections. Highly purified 0.5% and 1.0% agarose gels were prepared and a series of enoxaparin concentrations was added to both gels for comparison and optimization. The 0.2% toluidine blue stain was prepared by the addition of 1 ml in an ethanol-water-acetic acid mixture (50:49:1; v/v/w). The staining process comprised two steps: first, toluidine blue was added for 30 min and destained overnight in the solvent mixture. Subsequently, the following morning, the second step was conducted, in which the gel was restained for 30 min with the same concentration of toluidine blue. We continued to stain the gel until the bands were visible.

Results: The gel electrophoresis results showed that clearest and sharpest bands were obtained using 65–75 mAh and 85 V settings. At 95 mAh, the bands were slightly washed out.

Conclusion: This study successfully facilitated the detection of enoxaparin, a LMWH, and heparin in the laboratory by using simple tools and techniques available in most laboratories.

Keywords: Gel electrophoresis, Low-molecular-weight heparin, Method optimization, toluidine blue

© 2019 The Authors. Published by Innovare Academic Sciences Pvt Ltd. This is an open access article under the CC BY license (http://creativecommons.org/licenses/by/4.0/)
DOI: http://dx.doi.org/10.22159/ijpps.2019v11i4.31655

INTRODUCTION

Crude heparin contains several impurities and requires purification before it is ready for the pharmaceutical market [1]. The most common impurities are dermatan sulfate (DS) and chondroitin sulfate (CS). Several electrophoretic methods have been used to detect the purity and quality of heparin, such as capillary electrophoresis (CE), polyacrylamide gel electrophoresis (PAGE), and agarose gel electrophoresis [2]. In addition to electrophoretic assays, sophisticated methods are also essential to receive approval US Food and Drug Administration (FDA), such as nuclear magnetic resonance (NMR) and liquid chromatography-mass spectrometry (LC-MS) [3]. Heparin is a heterogeneous molecule that exists as molecules of variable molecular mass, ranging from 3,000 to 40,000 Da. However, low-molecular-weight heparins (LMWH) contain less variation in mass and are more purified in the manufacturing process than other heparins [4]. As LMWH is a degradation product of heparin and is more purified, it is easier to detect on a gel than unfractionated heparin (UFH) [2, 4].

CE is a validated and sensitive technique for the separation of sulfated and non-sulfated glycosaminoglycans (GAGs). The limitations of this method include wide peaks, partial separation of contaminants, and limited resolution [5]. Several studies have applied further modifications of this method to enhance its reliability, sensitivity, and resolution for impurity separation [6-8]. PAGE is another essential method for the characterization of UFH and LMWH and is valuable for purifying the over-sulfated CS (OSCS) impurities [9]. Similarly, the PAGE method has been subjected to several improvements and developments to enhance it's precision and reliability [10]. In contrast, although agarose gel electrophoresis is a simple and widely used approach, only a few researchers have utilized the technique for heparin purification [11]. In general, agarose gel electrophoresis can be used to separate the main impurities, such as OSCS, DS, and CS, by using high-voltage electrophoresis overnight. Furthermore, gel electrophoresis can separate UFH and LMWH in simple steps at a reasonably low cost [12]. The advantage of this method is its availability and accessibility by most laboratories. This study aimed to optimize the detection of enoxaparin, low-molecular-weight heparin, by using simple electrophoretic steps with a simple and cheap staining process.

MATERIALS AND METHODS

Several gel electrophoresis procedures were performed to test and optimize the detection of enoxaparin using a simple modification in the approach by Volpi [12]. This method was developed to simplify the detection of LMWH by using a gel. Therefore, several gel thicknesses, voltage settings, and enoxaparin concentrations were tested in the optimization procedure. Enoxaparin was purchased from a local supplier as pre-filled pharmaceutical injections. The electrophoresis cell instruments were prepared. Highly purified 0.5% and 1% agarose gels were prepared for the comparison. Both gels were immersed in 0.04 M barium acetate buffer at a pH of approximately 5.8. Serial dilutions of enoxaparin were added to both gels for comparison and optimization. All enoxaparin samples were layered into the cells at a volume of 0.5 µl/cell. A buffer of 0.05 M 1,2-diaminopropane was added, followed by acetic acid to adjust the pH to 9.0. The current was applied for 15 min at 4 °C, at 65, 75, 85, and 95 mAh and 85 V. After electrophoresis, the gels were immersed in 0.2% cetylpyridinium chloride for 3 h as part of the washing process. The toluidine blue stain was prepared at 0.2% in 1 ml of a mixture of ethanol-water-acetic acid (50:49:1; v/v/w). The staining process was completed in two steps: first, toluidine blue was added for 30 min, followed by destaining with a 0.2% ethanol-water-acetic acid (50:49:1; v/v/w) solution overnight. The following morning, the gel was restained for another 30 min using the same concentration of toluidine blue. The staining process was continued until clear bands were visible on the gel. The analysis was performed by using a densitometer scanner (Macintosh ɪɪsi with Microtek International Interface).

RESULTS

Optimal conditions were identified from the electrophoresis of the solutions in different thicknesses of gels, currents, voltages, and heparin concentrations.

Table 1: Electrophoresis materials

Item Manufacturer
Agarose gel Sigma-Aldrich, USA
Barium acetate Panreac Chemicals, Barcelona, Spain
Electrophoresis apparatus C. B. S. Scientific Co., CA, USA
Hexadecyltrimethylammonium bromide Sigma-Aldrich, UK
Toluidine blue LOBA Chemie, India
Ethanol Fisher Scientific, UK
Acetic acid Winlab, UK
Clexane Sanofi Aventis, France

Fig. 1: Comparison of different enoxaparin and heparin concentrations resolved by 0.5% agarose gel electrophoresis at 85 V and 65 mA. The stock solution at 100% concentration was added as a standard. UFH, unfractionated heparin; LMWH, low-molecular-weight heparin

Fig. 2: Comparison of different enoxaparin and heparin concentrations resolved by 1% agarose gel electrophoresis at 85 V and 65 mA. The stock solution of 100% concentration was added as the standard solution. UFH, unfractionated heparin; LMWH, low-molecular-weight heparin

Fig. 3: Comparison of different enoxaparin concentrations resolved by 1% agarose gel electrophoresis at 85 V and 75 mA. UFH, unfractionated heparin; LMWH, low-molecular-weight heparin

Fig. 4: Comparison of different enoxaparin concentrations resolved by 1% agarose gel electrophoresis at 85 V and 85 mA. UFH, unfractionated heparin; LMWH, low-molecular-weight heparin

Fig. 5: Comparison of different enoxaparin concentrations resolved by 1% agarose gel electrophoresis at 85 V and 95 mA. UFH, unfractionated heparin; LMWH, low-molecular-weight heparin

DISCUSSION

A simple gel electrophoresis method to allow further identification and purification of LMWH is required in numerous laboratories. In this study, we successfully established a simplified detection method for enoxaparin (a low-molecular-weight heparin) and heparin in the laboratory by using simple tools and techniques that are widely available in most laboratories. Although other gel-based methods have been approved for heparin identification, such as capillary electrophoresis, a simple gel agarose electrophoresis method would be an indispensable tool [3].

Gel thickness plays an important role in the performance of gel electrophoresis for the detection of various substances. Most published data used 0.5% highly purified gels [13] for the detection of heparin and LMWH; as we did not find any differences between 0.5% and 1% gels, the use of 0.5% gels would be more cost-effective. Ideally, higher enoxaparin concentrations create wider, overlapping bands (fig. 1 and 2). Extremely low concentrations, such as those ≤10%, may generate very bright bands if the procedure is not performed correctly. Thus, a concentration range of 20%–25% is a more reasonable choice and provides clear non-overlapping bands. Other studies have used different concentrations based on the provided standards [1, 12].

The applied voltage and time are both essential to a successful separation and in this study, the separation of enoxaparin was mainly evaluated at 85 V and 65–100 mAh. We also investigated the separation at 75, 85, and 95 mAh. At 65–85 mAh, all the bands appeared to be well separated and the most efficient separation was observed at 85 mAh. This allowed the bands to shift toward the end of the gel, which might not be necessary. At 95 mAh, some bands were washed out of the gel; thus, this voltage was unsuitable. Other studies have reported that full separation was achieved at 100 mAh, but the exact running voltage was not specified.

Staining is the final step, but several studies have failed to detect LMWH and heparin using agarose gel electrophoresis with the most commonly used dye, toluidine blue. However, others succeeded easily [11]. Thus, the sequential use of other dyes has been proposed following toluidine blue, such as Stains-all, especially when GAGs are unavailable [12]. In this study, we did not detect any bands after the first staining process and therefore we repeated the same staining process with the expectation that the bands would be clear. This is the first study to report the successful use of repeated staining with toluidine blue with various gel processing conditions.

CONCLUSION

Agarose gel electrophoresis is a simple and widely available method that can be used for the detection and purification of enoxaparin and heparin. Repeated (double) staining with toluidine blue may enhance the band clarity.

ACKNOWLEDGMENT

We would like to thank Qassim University for providing the chemicals and laboratories. Special thanks go to Mr. Casimero A. Victoria Jr., a key member of these laboratories.

CONFLICT OF INTERESTS

We have no conflicts of interest to declare
