Int J Pharm Pharm Sci, Vol 7, Issue 3, 136-139Original Article


INFLUENCE OF CARBON AND NITROGEN SOURCE ON GROWTH, DON AND NIV PRODUCTION BY TWO SPECIES OF FUSARIUM ISOLATED FROM FINGER MILLETS

P. SHILPA, V. KOTESWARA RAO*, K. NARASIMHA RAO, S. GIRISHAM, S. M. REDDY

Department of Microbiology, Kakatiya University, Warangal, Telangana, India.
Email: koti_micro08@yahoo.co.in

Received: 10 Dec 2014 Revised and Accepted: 01 Jan 2015

ABSTRACT

Objective: Influence of different carbon [C] and nitrogen [N] source on the growth and Deoxynivalenol [DON] and Nivalenol [NIV] production by Fusarium aethiopicum and Fusarium culmorum was investigated.

Methods: Seven days old monosporic cultures of F. aethiopicum strain GSKUMB [KJ21085] and F. culmorum strain GSKUMB [KJ190159] were grown in CYA broth and incubated at 27±2°C on the rotary shaker at 120 rpm for 21 days. At the end of incubation period, cultures were harvested for determination of fungal growth (biomass). The resultant culture filtrates were extracted twice with ethyl acetate and concentrated. One ml of final concentrate in methanol was employed for detection of DON and NIV with the help of RP-HPLC.

Results: The highest amount of DON and NIV were produced by F. aethiopicum in the presence of D-mannose and D-galactose as C source, while the highest amount of biomass was recorded on maltose and succinic acid. F. culmorum produced maximum amount of toxins in the presence of D-glucose, D-mannitol and D-fructose. Sodium nitrate was most favorable nitrogen source as it induced maximum amount of toxins by F. aethiopicum, while L-methionine, L-asparatic acid and L-tryptophan were next preferred N source. In contrast, highest biomass of fungus was obtained with L-lysine, L-glutamine and L-tyrosine. F. culmorum produced maximum amount of toxin and biomass with potassium nitrate and L-tyrosine respectively.

Conclusion: Present species of Fusarium differed varied both in toxins (DON, and NIV) and biomass production. Their response of fungi under investigation towards C and N sources is also varied.

Keywords: F. aethiopicum, F. culmorum, PCR, Carbon Sources, Nitrogen Sources; DON, NIV, HPLC.

INTRODUCTION

Mycotoxins, secondary metabolites, produced by fungi on agricultural commodities both in the field and storage vary with environmental condition [1]. These mycotoxins are stable at high temperatures in processed food [2]. The contamination of food and feeds with mycotoxins are of great concern as these are responsible for many acute and chronic diseases [3]. Among these aflatoxin, ochratoxin, citrinin, patulin, trichothesene, fumonisins and zearalenone are the most common contaminants of food and feeds [4]. Species of Fusarium are known to be plant pathogens but also contaminate foods and feeds, and elaborate variety of mycotoxins which are health hazardous [5].

The risk due to mycotoxins in food and feed is increasing and posing a significant threat of human and animal health. Mold growth and mycotoxin contamination are likely to reduce the nutritive quality of food and feeds more than one mycotoxin in food and feed is likely to increase toxicity due to synergetic action [6]. The production of mycotoxins is likely to be influenced by intrinsic and extrinsic factors [7]. It is also clear that the mycotoxin profile of a fungal species likely to depend up on the nutritional composition of substratum [6].

Fusarium species are the major concern due to their wide spread infestation of food grains [8, 9] and elaboration of variety of trichothecene mycotoxins [10]. The trichothecene producing Fusarium culmorum, F. graminearum, F. poae and F. sporotrichioides are most common contaminants of food grains [11]. F. graminearum and F. culmorum are the main producers of potent DON and NIV (Chemical structure) which are known to be carcinogenic, genotoxic, immuno­suppressive, teratogenic and inhibit protein synthesis. F. aethiopicum is indistinguishable morphologically from F. graminearum [12].

However, very limited information is available on production of DON and NIV by F. aethiopicum and F. culmorum. Hence, the present investigations were aimed to study influence of carbon and nitrogen source on growth, DON and NIV production by two species of Fusarium associated with Finger millets [Eleusine coracana L.] was assessed with the help of liquid chromatography and the results are discussed in this communication.

MATERIALS AND METHODS

Isolation and Identification of Fusarium species

Fusarium species associated with the finger millets were isolated and identified with the help of standard keys and manuals [13, 14]. The morphologically identified F. aethiopicum and F. culmorum were further confirmed by precise molecular methods by polymerase chain reaction [PCR] and the obtained nucleotide sequences were submitted to National Center for Biotechnology Information [NCBI] with GenBank Accession number F. aethiopicum strain GSKUMB [KJ21085] and F. culmorum strain GSKUMB [KJ190159].

Influence of carbon source on growth, DON and NIV production

The influence of different C sources on growth and DON and NIV production by F. aethiopicum and F. culmorum was studied by substituting sucrose of the basal medium with different C sources [D-glucose, D-fructose, D-mannose, D-galactose, starch, D-xylose, D-sorbose, D-mannitol, sucrose, D-lactose, D-maltose, citric acid, succinic acid, tartaric acid, D-raffinose, tannic acid, melibiose and dextrin] so as to supply same amount of carbon in triplicate (n=3). Sucrose served as control. Ehrlenmeyer flask (250-ml) containing 100 ml broth at pH 6.5 was inoculated with 1 ml of spore suspension [10-5] of F. aethiopicum and F. culmorum and incubated at 27±2°C in a rotary shaker [Yiedher LM-450D] at 120rpm for 21 days. At the ends of an incubation period, final pH of the broth, biomass and DON and NIV production was quantified by HPLC.

Influence of nitrogen source on growth, DON and NIV production

The influence of different N source on growth and, DON and NIV production by F. aethiopicum and F. culmorum was studied by adding different N source in place of sodium nitrate [ammonium chloride, ammonium molybdate, ammonium nitrate, ammonium sulphate, aluminium nitrate, barium nitrate, potassium nitrate and thiourea urea, L-glutamic acid, L-glutamine, L-glycine, L-alanine, L-arginine, L-asparagine, L-aspartic acid, L-cysteine, L-histidine, L-leucine, L-lysine, L-tyrosine, L-tryptophan, L-methionine, p-amino benzoic acid, p-nitroaniline and p-nitrobenzoic acid and urea] so as to supply same amount of nitrogen in triplicate (n=3).

The final pH of the culture broth was also determined with the help of Elico pH meter. Sodium nitrate served as control. The flasks thus prepared were inoculated with 1 ml of seven-day old culture spore suspension [10-5] of F. aethiopicum and F. culmorum and incubated as described above.

Determination of biomass of Fusarium species

At the end of 21 d incubation period, cultures of Fusarium species were harvested on pre-weighed Whatmann No.42 filter paper. The filter paper along with mycelial mat was dried in a hot air oven at 65-75°C for 72 hrs to obtain a constant weight in an analytical balance after cooling to room temperature in a desiccator in triplicate (n=3). The biomass yield per ml of medium was calculated.

Extraction and cleanup of DON and NIV

At the end of incubation period, cultures were harvested on Whatman filter paper No.42. The culture filtrate was centrifuged at 12,000g to get cell-free filtrates. The resultant culture filtrates were acidified with 0.1M o-phosphoric acid and extracted twice with ethyl acetate [1:1, v/v] and concentrated by rotary evaporator to get a final concentration of 1 ml in methanol and subjected to liquid chromatographic analysis.

Analysis and Quantification of DON and NIV by HPLC

Liquid chromatography [LC] analysis of OTA was carried out by using JASCO-975[Japan], C-18 isocratic reverse phase column [250X4.6 mm internal diameter, 5µM particle size] by injecting 20 µl of sample extract. The mobile phase for toxin consists of a mixture of methanol: water [70:30] [Sigma Aldrich, Mumbai, India]. The pH was adjusted, degassed using bath sonicator [PCITM Analytics].

The chromatography was performed isocritically at a flow rate of 0.5 ml/min at 227 nm under UV detector. The amount of DON and NIV produced was determined by HPLC fluorometric response compared with standard DON and NIV Sigma Aldrich [Mumbai, India].

RESULTS AND DISCUSSION

Influence of C source on growth, DON and NIV production by F. aethiopicum

The present investigations revealed that a definite influence on growth, DON and NIV production by both the species of Fusarium under study. F. aethiopicum produced maximum amount of DON and NIV on D- mannose followed by D-galactose, D-xylose, D-maltose and L-sorbose in a descending order, while it was least in the presence of succinic acid, citric acid and starch (Table 1). Rest of the C sources supported intermediate amount of toxins production.

The highest mycelial yield was recorded in the presence of D-maltose, succinic acid D-lactose and D-fructose, while, D-mannose, D-glucose and starch were responsible for the least growth. Rest of the C sources tried induced intermediate amount of biomass. In most of the cases final pH was alkaline. However, it was near neutral in the presence of D-mannose, D-galactose and D-xylose. Final pH recorded was acidic in media containing rest of the carbon sources tried. Tartaric acid, D-raffinose, tannic acid, melibiose and dextrin failed to support growth, DON and NIV production by both the species of Fusarium under study.

Influence of C source on growth, DON and NIV production by F. culmorum

D-glucose, D- mannose, D-mannitol and D-fructose were responsible for the highest amount of DON and NIV production by F. culmorum, while succinic acid, citric acid and starch were poor substrates for production of both the mycotoxins under study. Rest of the C sources tried supported intermediate amount of toxin production. L-sorbose, D-mannitol, D-lactose and D-xylose supported maximum biomass, while D-mannose, D-galactose and succinic acid was responsible for least growth of the F. culmorum. Rest of the C sources were responsible for intermediate amount of biomass production. Final pH of the medium was alkaline in media containing D-glucose, D-mannose and D-xylose, while in D-fructose, starch and L-sorbose media it was neutral.

Influence of N source on growth, DON and NIV production F. aethiopicum

The highest amount of DON and NIV production was recorded in presence of sodium nitrate, L-methionine, potassium nitrate, L-asparatic acid, L-tryptophan, urea and ammonium sulphate (Table 2) while, ammonium molybdate, ammonium chloride, L-arginine, L-lysine and L-histidine were responsible for least amount of DON and NIV production. Rest of the N source supported intermediate amount toxins production. Biomass accomplished by F. aethiopicum was maximum in medium containing L-lysine, L-glutamine, L-tyrosine, and L-tryptophan, while it was least in medium containing L-glutamic acid, potassium nitrate, L-histidine and L-aspartic acid.

Influence of N source on growth, DON and NIV production F. culmorum

F. culmorum produced maximum DON and NIV when potassium nitrate, ammonium sulphate, L-aspartic acid, L-tryptophan and L-methionine were served as N source, while ammonium molybdate, ammonium chloride, L-alanine, L-arginine and L-histidine were supported poor sources for production of DON and NIV. Rest of the N sources were responsible for intermediate amount DON and NIV production. Maximum biomass production was recorded in media containing L-tyrosine, potassium nitrate, L-glycine and L-arginine. Aluminium nitrate, barium nitrate, p-amino benzoic acid, p-nitro benzoic acid, p-nitro aniline and thiourea failed to support the growth of F. culmorum.

Least amount of biomass was recorded in medium containing L-histidine, L-lysine, L-leucine, ammonium chloride and ammonium sulphate. Rest of the N sources supported the intermediate amount of biomass. The final pH recorded in medium containing L-alanine, ammonium sulphate, L-glutamine, L-glycine, L-asparagine, L-histidine, L-lysine, L-leucine and L-tryptophan was alkaline. On the other hand, pH was neutral in medium containing ammonium chloride, ammonium molybdate, ammonium nitrate and sodium nitrate.

Present investigations are aimed to find the nutritional composition of the medium for growth, DON and NIV production by F. aethiopicum and F. culmorum was studied. DON and NIV production was recorded maximum in media containing D- mannose, D-galactose, xylose, while it was least in media containing succinic acid, citric acid and starch in agreement with Koteswara Rao et al. [15] who also reported critical role of C and N sources on OTA production by P. verrucosum and P. nordicum. The present investigations are also in agreement with [16] who also recorded critical influence of carbon and nitrogen source on alternariol [AOH], alternariol mono methyl ether [AME] and tenuazonic acid [TA] by Alternaria alternata. A positive correlation was observed between growth and DON and NIV production by both the species of Fusarium under investigations.

Table 1: Influence of carbon source on growth, DON and NIV production by two species of Fusarium isolated from finger millets

F. aethiopicum F. culmorum
Carbon source Final pH Dry. wt [mg/ml] DON [µg/ml]
D-Glucose 8.13±0.25 2.40±0.15 25.20±0.89
D-Fructose 8.3±0.17 4.30±0.15 32.90±0.64
D-Mannose 7.53±0.35 2.10±0.26 48.50±0.87
Galactose 7.56±0.35 3.10±0.35 31.80±0.52
Starch 6.93±0.45 2.50±0.40 18.20±0.55
D-Xylose 7.5±0.60 3.20±0.26 33.20±0.58
L-Sorbose 8.16±0.40 3.60±0.10 41.90±0.86
Mannitol 6.93±0.83 4.20±0.10 35.80±0.31
Lactose 6.50±0.30 4.40±0.17 35.80±0.38
Maltose 7.36±0.37 5.30±0.36 33.90±0.91
Citric acid 3.43±0.25 2.90±0.40 10.80±0.33
Succinic acid 2.86±0.30 4.50±0.23 9.11±0.37
Tartaric acid 6.10±0.45 0.00±00 0.00±00
D-Raffinose 6.76±0.30 0.00±00 0.00±00
Tannic acid 6.89±0.20 0.00±00 0.00±00
Melibiose 6.30±0.26 0.00±00 0.00±00
Dextrin 5.36±0.20 0.00±00 0.00±00
Sucrose [Control] 7.96±0.40 3.90±0.43 33.50±0.87

Table 2: Influence of nitrogen source on growth, DON and NIV production by two species of Fusarium isolated from finger millet

F. aethiopicum F. culmorum
Nitrogen source Final pH Dry. wt [mg/ml]
Ammonium chloride 7.73±0.32 5.26±0.288
Ammonium molybdate 7.03±0.49 7.4±0.1
Ammonium nitrate 7.83±0.25 4.43±0.20
Ammonium sulphate 8.33±0.25 4.4±0.43
Aluminium nitrate 5.2±0.4 0.00±0.00
Barium nitrate 5.33±0.15 0.00±0.00
L-glutamic acid 6.3±0.45 2.5±0.3
L-glutamine 8.23±0.40 6.56±0.50
L-glycine 8.06±0.51 5.3±0.2
L-alanine 8.40±0.36 3.83±0.32
L-arginine 7.16±0.35 5.1±0.26
L-asparagine 8.03±0.60 4.81±0.70
L-aspartic acid 6.83±0.30 3.66±0.60
L-cystine 6.76±0.45 4.66±0.45
L-histidine 8.26±0.15 3.06±0.32
L-lysine 8.23±0.30 7.06±0.51
L-leucine 8±0.26 4.16±0.45
L-tryptophan 8.36±0.46 5.46±0.28
L-tyrosine 6.96±0.20 6.36±0.15
L-methionine 6.66±0.51 4.03±0.30
p-amino benzoic acid 4.2±0.5 0.00±0.00
p-nitrobenzoic acid 3.53±0.30 0.00±0.00
p-nitroaniline 5.5±0.26 0.00±0.00
Potassium nitrate 8.26±0.28 2.86±0.35
Thiourea 6.4±0.26 0.00±0.00
Urea 6.93±0.90 4.4±0.75
Sodium nitrate [Control] 7.3±0.52 4.76±0.56

The present observation is in agreement with Narasimha Rao et al. [17] who also opined that nutritional composition of the media play a major role in production fumonisins. DON and NIV production by species of Fusarium differed with the nutritional composition of the medium and environmental condition [18]. DON is vomitoxin and provokes acute and chronic disease in humans and animals [19]. It is also reported to induce inhibition of protein, DNA and RNA synthesis and mitochondrial function and affects cell division [20].

Environmental factors such as humidity and water availability, temperature and nutritional availability are reported to affect vegetative growth and toxin production by species of Fusarium [21]. The results of the present study are positively correlated with the reports of Ferreira and Pitout [22] who also recorded highest OTA production in the presence of sucrose and considerably low on D-glucose present in the medium. Medina et al. [23] recorded significant influence of nitrogen and carbon sources on OTA production by Aspergillus species. A. ochraceus, A. carbonarius and A. tubingensis are reported to produce maximum OTA in the presence of sucrose, D-glucose as C source and arabinose and phenylalanine as N source. No positive correlation was observed between DON and NIV productions by the species of Fusarium under investigation. Shilpa et al. (24) also reported the variability in DON and NIV production with the cultural and nutritional condition.

Present investigations F. aethiopicum and F. culmorum were grown different C and N sources at pH 6.5, after an incubation period, the final pH varied due to production of mycotoxin in the medium are positively correlated with Wheeler et al. [25] who also reported that of pH was ideal for mold growth and mycotoxin production.

CONCLUSION

Carbon and nitrogen sources present in the medium significantly influenced the growth and DON and NIV production by F. aethiopicum and F. culmorum. Thus, regulating these nutrients it is possible to minimize the growth of both the species of Fusarium and toxin production under investigations and protect the foods and feeds during their production and distribution.

ABBREVIATION

C: Carbon, N: Nitrogen, DON: Deoxynivalenol, NIV: Nivalenol , CYA: Czepak Yeast Autolysate Agar, RP-HPLC: Reverse Phase High Performance Liquid Chromatography, HPLC: High Performance Liquid Chromatography, National Center for Biotechnology Information [NCBI], OTA: Ochratoxin A

ACKNOWLEDGEMENT

This research has been supported by the Head Department of Microbiology, Kakatiya University, India.

CONFLICT OF INTERESTS

Declared None.

REFERENCES

  1. Drusch S, Ragab W. Mycotoxins in fruits, fruit juices and dried fruits. J Food Prot 2003;66:1514–27.
  2. Abrunhosa L, Robert R, Paterson M, Venancio A. Biodegradation of Ochratoxin A for food and feed decontamination. Toxins 2010;2:1078-99.
  3. De Vries JW, Trucksess MW, Jackson LS. Mycotoxins and food safety. Kluwer New York; 2002. p. 1–298.
  4. Sforza S, Dall’asta C, Marchelli R. Recent advances in mycotoxin determination in food and feed by hyphenated chromatographic techniques/mass spectrometry. Mass Spectrom Rev 2006;25:54–76.
  5. Venkataramana M, Shilpa P, Balakrishna K, Murali HS, Batra HV. Incidence and multiplex PCR based detection of trichothecene chemotypes of Fusarium culmorum isolates collected from freshly harvested Maize kernels in Southern India. Braz J Microbiol 2013;44:401-6.
  6. Koteswara Rao V, Ramana MV, Girisham S, Reddy SM. Culture media and factors influencing ochratoxin a production by two species of penicillium isolated from poultry feeds. Natl Acad Sci Lett 2013;36:101-10.
  7. Shilpa P, Koteswara Rao V, Girisham S, Reddy SM. Natural incidence of fusarial mycotoxins in finger millet [Eleusine coracana L.] of AP, India. Asiatic J Biotechnol Resor 2011;2:392-402.
  8. Bhat R, Rai RV, Karim AA. Mycotoxins in food and feed: Present status and future concerns. Comp Rev Food Sci Food Safety 2010;9:57-81.
  9. Wilson A, Simpson D, Chandler E, Jennings P, Nicholson P. Development of PCR assays for the detection and differentiation of Fusarium sporotrichioides and Fusarium langsethiae. FEMS Microbiol Lett 2004;233:69–76.
  10. Fredlund E, Gidlund A, Pettersson H, Olsen M, Börjesson T. Real-time PCR detection of Fusarium species in Swedish oats and correlation to T-2 and HT-2 toxin content. World Mycotox J 2010;3:77–88.
  11. O’Donnell K, Ward TJ, Geiser DM, Kistler HC, Aoki T. Genealogical concordance between the mating type locus and seven other nuclear genes supports formal recognition of nine phylogenetically distinct species within the Fusarium graminearum clade. Fungal Genet Biol 2004;41:600–23.
  12. Filtenborg O, Frisvad TC, Samson R A. Specific association of fungi in foods and influence of physical environmental factors. In: RA Samson, ES Hoekstra, JC Frisvad, O Filtenborg, Eds. Introduction to food-and airborne fungi utrecht: Centralbureau voor Schimmelculture; 2000;6:306-20.
  13. Samson RA, Hoekstra, Van Oorschot CN. Introduction to food-borne fungi. Institute of the royal Netherlands. Acad Arts Sci 1984;217-36.
  14. Nelson PE, Toussoun TA, Marasas WF. Fusarium species: an illustrated manual for identification. The Pennsylvania State University Press: University Park; 1983. p. 193.
  15. Koteswara Rao V, Venkataramana M, Girisham S, Reddy SM. Influence of carbon and nitrogen source on ochratoxin A by two species of Penicillium isolated from poultry feeds. Arch Phytopathol Plant Protection 2012;45:1917-27.
  16. Brzonkalik K, Dominik Hümmer, Christoph Syldatk, Anke Neumann. Influence of pH and carbon to nitrogen ratio on mycotoxin production by Alternaria alternata in submerged cultivation. AMB Express 2012;2:1-28.
  17. Narasimha Rao K, Vijaypal Reddy B, Girisham S, Reddy SM. Factors influencing fumonisins [B1] production by Fusarium moniliforme. Indian J Sci Technol 2010;3:213–5.
  18. Payne GA. Ear and kernel rots. In: White DG, ed. Compendium of corn diseases. The American Phytopathol Society Press: St Paul; 1999. p. 44–7.
  19. Goswami RS, Kistler HC. Heading for disaster: Fusarium graminearum on cereal crops. Mol Plant Pathol 2004;5:515–25.
  20. Pestka JJ. Toxicological mechanisms and potential health effects of deoxynivalenol and nivalenol. World J Mycotoxin 2010;3:323–47.
  21. Wegulo SN. Factors influencing deoxynivalenol accumulation in small grain cereals. Toxins 2012;4:1157–80.
  22. Ferreira NP, Pitout MJ. The biosynthesis of ochratoxin. J South Afr Chem Inst 1969;22:S1.
  23. Medina A, Mateo EM, Valle Algarra FM, Mateo F, Mateo R, Jimenez M. Influence of nitrogen and carbon sources on the production of ochratoxin A by ochratoxigenic strains of Aspergillus spp. isolated from grapes. Int J Food Microbiol 2008;122:93–9.
  24. Shilpa P, Koteswara Rao V, Girisham S, Reddy SM. Factors influence on growth, DON and NIV production by two species of Fusarium isolated from Finger millets [Eleusine coracana L.]. Int J Pharm Pharm Sci 2014;6:11:312-7.
  25. Wheeler KA, Hurdman BA, Pitt JF. Influence of pH on the growth of some toxigenic species of Aspergillus, Penicillium and Fusarium spp. Int J Food Microbiol 1991;12:141-50.
