School of Pharmacy, RK University
Email: devang.pandya@rku.ac.in
Received: 21 Sep 2015 Revised and Accepted: 25 Nov 2015
ABSTRACT
Objective:Punarnava is a controversial drug i.e. its true botanical identity has not been ascertained, and several different species are used as Punarnava. It is a part of many medicinally important traditional formulations. Ayurvedic Pharmacopoeia of India describes three different species–Roots of Boerhaavia diffusa, Trianthema portulacastrum and Boerhaavia verticillata. The present work deals with the microscopic, macroscopic and phytochemical comparison of the roots of these species of Punarnava, so as to differentiate them and establish their quality parameters.
Methods:Roots of these three species were collected, and their comparative morphological, microscopical (transverse section, powder study) and the phytochemical (screening, tannin estimation) study was performed.
Results:Roots of Boerhaavia diffusa showed morphological characteristics which clearly distinguished it from the other species. Theyshowed the presence of well developed and stratified cork, abnormal vascular bundles which were discontinuous, and a central cavity, presumably formed due to the disintegration of tissues. Boerhaavia verticillata showed the presence of xylem bundles arranged in the form of a ‘X’-shaped cross in the central region. Thick-walled cork cells and pitted xylem vessels were present only in Boerhaavia diffusa root powder, whereas bundles of fibrovascular tissue were present only in the powder of Boerhaavia verticillata. Tannin content was found to be highest in Boerhaavia diffusa roots.
Conclusion:The present investigation will help herbal industries and traditional medicinal practitioners to detect adulteration of the medicinally important immunomodulator Boerhaavia diffusa by Trianthema portulacastrum and Boerhaavia verticillata, which are considered to have no immunomodulatory activity.
Keywords: Boerhaavia diffusa, Boerhaavia verticillata, Controversial drug, Immunomodulator, Microscopy, Nyctaginaceae, Punarnava, Quality Control, Standardization, Trianthema portulacastrum
© 2016 The Authors. Published by Innovare Academic Sciences Pvt Ltd. This is an open access article under the CC BY license (http://creativecommons.org/licenses/by/4.0/)
INTRODUCTION
Punarnava is a ‘controversial drug’ because its true botanical identity has not been ascertained yet. Various species are known by the name of ‘Punarnava’. Ayurvedic Pharmacopoeia of India describes three species–Roots of Boerhaavia diffusa, Trianthema portulaca strum and Boerhaavia verticillata.
Roots of Boerhaavia diffusa (B. diffusa) syn. Boerhaavia repens, Boerhaavia procumbens (Family–Nyctaginaceae, also known as Rakta Punarnava) are traditionally used as an immunomodulator, adaptogenic, diuretic, anti-arthritic, analgesic, anti-fibrinolytic, blood purifier, hypotensive, hepatoprotective, anti-anemic, antioxidant, anti lymphoproliferative and in edema and dropsy [1, 2]. Punarnava roots available in the market are normally the roots of B. diffusa.
Roots of Trianthema portulaca strum (T. portulaca strum) syn. Trianthema monogyna (Family–Ficoidaceace, also known as Varshabhu, Shwet Punarnava) are used traditionally as antipyretic, analgesic, spasmolytic, deobstruent, cathartic, anti-inflammatory, in diseases of liver and spleen, anaemia and edema [3, 4].
Roots of B. verticillata (Family–Nyctaginaceae, also known as Vrischiva, Shwet Punarnava) are used traditionally as digestive, appetizer, antipyretic, the antidote for poisonous bites of insects, anti-leprotic, anti-cough and in disorders of the heart, spleen and gastrointestinal tract [5, 6].
Roots of T. portulacastrum and B. verticillata are rarely available in the market, and none of them being immunomodulators, are considered to be adulterants of B. diffusa.
No work has been done so far to distinguish the three species from each other, which is crucial for ascertaining the actual species of ‘Punarnava’ and for its quality control. The present investigation deals with pharmacognostic and phytochemicals evaluation of roots of the three species, thereby setting parameters which will help herbal industries to detect adulteration of B. diffusa by T. portulaca strum and B. verticillata, thereby ultimately benefiting the patients.
MATERIALS AND METHODS
Dried roots of B. diffusa were obtained from Yucca Enterprise, Mumbai, whereas roots of T. portulacastrum and B. verticillata were collected from the herbal garden of School of Pharmacy, RK University (22 ° 14' 27.1284'' N, 70 ° 54' 3.4308'' E) in flowering season in July, 2014. The samples were authenticated were authenticated by Dr. Kunjal Soni, Botanist, School of Science, RK University, and deposited in the institute repository. The roots were compared morphologically and used for transverse section study. The roots were dried, powdered, stored in airtight containers and used for phytochemical studies. For microscopical studies, safranin was used for staining [7]. Photomicrography of the transverse sections and the powdered drug was performed using the camera. Phytochemical screening of both the species was performed using the appropriate extracts (aqueous and alcoholic) (table 2) [8-12]. Total tannins were estimated in all species [13].
RESULTS
Macroscopy
Roots of B. diffusa were cylindrical, deep brown, thick, 6-8 cm X 0.5-1 cm, with a rough surface and no lateral roots. Roots of T. portulacastrum were also cylindrical, creamish-white, very thin, 4-5 cm X 0.1-0.2 cm, with a smooth surface and many hairy secondary rootlets. Roots of B. verticillata were cylindrical, creamish-white, very thin, 6-10 cm X 0.1-0.4 cm, with a smooth surface and many hairy secondary rootlets (fig. 1).
|
|
A |
B |
Fig. 1: Morphology of various species of Punarnava A: Entire plant of T. portulaca strums (Right) and B. verticillata (Left); B: Roots of T. portulaca strum (Right), B. verticillata (Centre) and B. diffusa (Left)
Microscopy: transverse section
In B. diffusa, the cork was well developed and stratified, consisting of 8-10 layers of large, thin-walled cells followed by 4-5 layers of small, compact, suberized cells. Underlying the cork were 4-5 layers of parenchymatous cortical cells containing acicular crystals of calcium oxalate, brownish matter and starch grains. Underlying the cortex were the discontinuous anomalous vascular bundles consisting of successive and alternate layers of phloem and xylem. The phloem in the centre normally degrades to form a cavity (fig. 2 a, b).
In T. portulaca strum, the cork was not well-developed and not stratified, consisting of 2-3 layers of large, thin-walled cells. Underlying the cork were 4-5 layers of large, parenchymatous cortical cells containing acicular crystals of calcium oxalate, brownish matter and starch grains. Underlying the cortex were the continuous anomalous vascular bundles consisting of successive and alternate layers of phloem and xylem. No cavity was present in the centre due to the presence of xylem elements and absence of phloem (fig. 3 a, b).
In B. verticillata, the cork was not well-developed and not stratified, consisting of 2-3 layers of large, thin-walled cells. Underlying the cork was a cortex similar to T. portulaca strum. Underlying the cortex were the continuous anomalous vascular bundles consisting of successive and alternate layers of phloem and xylem. No cavity was present in the centre due to the presence of xylem elements. The most striking feature in the central region of the root was the presence of four xylem bundles arranged perpendicular to each other in the form of a ‘X’-shaped cross (fig. 4 a, b).
Fig. 2a: Detailed T. S. of B. diffusa root in 10x cork and cortex (Left); vascular bundles (right)
Fig. 2b: Detailed T. S. of B. diffusa root in 45x cork and cortex (Left); vascular bundles (right)
Fig. 3a: Detailed T. S. of T. portulaca strum root in 10x Cork and cortex (Left); vascular bundles (right)
Fig. 3b: Detailed T. S. of T. portulaca strum root in 45x Cortex (Left); vascular bundles (right)
Fig. 4a: Detailed T. S. of B. verticillata root in 10x cork and cortex (Left); vascular bundles (right)
Fig.4b: Detailed T. S. of B. verticillata in 45x cork and cortex (Right); vascular bundles (left)
Microscopy: powder characteristics
In B. diffusa, the important diagnostic features of the powder included parts of cork cells in surface view having thick-walled cells, xylem fibers with a pointed end, pitted xylem vessels, single and compound starch grains and acicular calcium oxalate crystals (fig. 5a).
Powder of T. portulaca strum consisted of cork cells in surface view having thin-walled cells, xylem fibers with a pointed end, reticulately-thickened xylem vessels, single and compound starch grains and acicular calcium oxalate crystals (fig. 5b).
In powder of B. verticillata, the chief features included cork cells in surface view having thin-walled cells, a fibro-vascular tissue consisting of bundles of xylem vessels and xylem fibers and acicular crystals of calcium oxalate (fig. 5c).
Fig. 5a: Powder study of B. diffusa root (45x)(a; crk cel: cork cell, b; fbr: xylem fiber, d; xyl vesl: pitted xylem vessel, e; srch: starch grain, cal oxlt: calcium oxalate acicular crystals)
Fig. 5b: Powder study of T. portulaca strum root (45x) (a; stc grn: starch grain, b: crk cel: cork cell in surface view, c; xyl vesl: xylem vessel, d; fbr: xylem fiber
Fig. 5c: Powder study of B. verticillata root (45x) (a; fbr: fibro-vascular tissue, b; aclr crstl: acicular crystal, prsm crstl: prism crystal of calcium oxalate)
Table 1: Phytochemical screening
Phytoconstituent |
Test |
Result |
||
Boerhaavia diffusa |
Trianthema portulaca strum |
Boerhaavia verticillata |
||
Alkaloids |
Dragendorff’s test |
+ve |
+ve |
+ve |
Hager’s test |
+ve |
+ve |
+ve |
|
Wagner’s test |
+ve |
+ve |
+ve |
|
Mayer’s test |
+ve |
+ve |
+ve |
|
Flavonoids |
Shinoda test |
-ve |
-ve |
-ve |
Phenolics |
Ferric chloride test |
-ve |
-ve |
-ve |
Folin Ciocalteu test |
-ve |
-ve |
-ve |
|
Sterols and triterpenoids |
Salkowski test |
-ve |
-ve |
-ve |
Libermann-Buchardt test |
-ve |
-ve |
-ve |
|
Cardiac glycosides |
Legal test |
-ve |
-ve |
-ve |
Baljet test |
-ve |
-ve |
-ve |
|
Keller Killiani test |
-ve |
-ve |
-ve |
|
Saponin glycosides |
Foam test |
-ve |
-ve |
-ve |
Lead acetate test |
-ve |
-ve |
-ve |
|
Anthraquinone glycosides |
Modified Borntrager test |
-ve |
-ve |
-ve |
Carbohydrates |
Fehling’s test |
+ve |
+ve |
+ve |
Molisch test |
+ve |
+ve |
+ve |
Table 2: Estimation of tannins
B. diffusa |
T. portulacastrum |
B. verticillata |
12.99±0.5%w/v |
14.14±0.5%w/v |
12.48±0.5%w/v |
DISCUSSION
Punarnava is a ‘controversial drug’. Its true botanical identity has not yet been ascertained. Various species are known by the name of ‘Punarnava’. Ayurvedic Pharmacopoeia of India describes three species–Roots of Boerhaavia diffusa, Trianthema portulaca strum and Boerhaavia verticillata [1, 3, 5]. The present work deals with the microscopic, macroscopic and phytochemical comparison of the roots of these three species of ‘Punarnava’. Roots of B. diffusa showed morphological characteristics which clearly distinguished it from the other species. Microscopically, roots of B. diffusa showed the presence of well developed and stratified cork, abnormal discontinuous vascular bundles, and a central cavity, which distinguishes it from the other species. The unique microscopic feature of B. verticillata was the presence of xylem bundles arranged in the form of a ‘X’-shaped cross in the central region of the root. The presence of thick-walled cork cells and pitted xylem vessels were the diagnostic features of B. diffusa root powder, whereas bundles of fibrovascular tissue were present only in the powder of B. verticillata. Tannin content was highest in B. diffusa roots. Since no work has been reported so far distinguishing the three species, these diagnostic pharmacognostic characters & phytochemicals data are vital. As the Indian traditional system of medicine is getting worldwide acceptance nowadays, it is highly necessary to bring an end to controversies related to ascertaining the true botanical identity of species by establishing quality testing parameters for the medicinally important genuine species and distinguishing it from its adulterants and substitutes. Such a comparative study is particularly important in the case of Punarnava since only B. diffusa is considered to possess vital immunomodulatory properties, and so it needs to be distinguished from the other species.
CONCLUSION
‘Punarnava’ is present in various Ayurvedic formulations and thus has considerable medicinal importance. However, confusion still prevails over the true botanical identity of ‘Punarnava’. The present investigation will help herbal industries and traditional medicinal practitioners to detect adulteration of the medicinally important B. diffusa by T. portulacastrum and B. verticillata by simple microscopic and phytochemical methods, thereby helping in quality control and standardization of Punarnava formulations, ultimately benefiting the end-users.
CONFLICT OF INTERESTS
Declared None
